Button toggles a room light

Difficulty: Level 1

This is an alternative way to use the Starter Kit's button. Instead of toggling the kit's own RGB LEDs on the device, the button fires a Home Assistant automation that toggles any light in your home. Same physical button, but now it can target any entity or fire any script or scene in Home Assistant. It's one or the other, though: if you've already built the on-device Button Controlled LEDs automation, remove it in ESPHome Device Builder first, otherwise a single press toggles both the kit's RGB LEDs and your room light.

Before you start

Work through these pages first. This tutorial assumes your device is flashed, the Button module is wired up, and the kit is connected to Home Assistant:

Build the automation

You'll build a Home Assistant automation that toggles a light in your home each time you press the Button module.

  1. Open Settings → Automations & scenes in Home Assistant.

    Open your Home Assistant instance and show your automations.

  2. Click + Create automation in the bottom right, then choose Create new automation.

  3. Under Triggers, click + Add trigger, type state, and choose State.

    • In the Entity field, type button module and select Button Module.
    • To → On (1)
    1. The button registers as a binary sensor. On maps to a pressed state: the moment you push the button down. Home Assistant fires the automation at that instant.

    Home Assistant automation editor adding a State trigger for Button Module with To set to On

  4. Under Then do, click + Add action, type toggle light, and select Light: Toggle.

    • Light: Toggle handles both directions: on if the light is off, off if it's on. (1)
    • Under Targets, click + Choose entity, search for your light such as Brandons Room, and select it. (2)
    1. If you'd rather it always turn on or always turn off, use Light: Turn on or Light: Turn off instead.
    2. You can also set a Color, Color temperature, or Brightness here for when the light turns on. Toggling it off ignores them.

    Adding a Toggle light action in Home Assistant and choosing Brandons Room as the target light

  5. Click Save.

  6. Give the automation a name like Button toggles room light, then click Save again.

    Home Assistant Save dialog naming the automation Button toggles room light, then clicking Save

What the automation looks like in YAML

Home Assistant stores automations as YAML. Select Edit in YAML from the three-dot menu on the automation to see or paste the raw config. Your entity IDs will differ from the example below.

alias: Button toggles room light
description: ""
triggers:
  - trigger: state
    entity_id:
      - binary_sensor.esphome_starter_kit_button_module
    to:
      - "on"
conditions: []
actions:
  - action: light.toggle
    metadata: {}
    target:
      entity_id: light.brandons_room
    data: {}
mode: single

Test the automation

Press the button on the Button module. The light you targeted toggles. Press again and it toggles back.

Your kit is now a physical remote for Home Assistant!

Any light in your home (a bedside lamp, a ceiling group, a smart bulb strip) is one button press away. Swap light.toggle for light.turn_on with a brightness_pct to land on a specific brightness, or target a light group to control a whole room at once.
